1 Amp Bridge Rectifier DB107

1 Amp Bridge Rectifier DB107

The DB107 is a compact full-wave bridge rectifier designed for converting AC input into stable DC output in low-power electronic circuits. Rated for 1 amp continuous current and 1000V peak reverse voltage, it is suitable for power supplies, chargers, LED drivers, and general-purpose AC-to-DC rectification.
Its small DB (DIP-style) molded package allows easy PCB mounting and offers clear polarity markings for simple, error-free installation.

Click here to view the related products

Features

• DC Output Current (IO): 1A
• Peak Reverse Voltage (VRRM): 1000V (DB107 version)
• Compact DB package for PCB mounting
• Low forward voltage drop
• High surge current capability
• Integrated full-wave bridge rectifier
• Terminals clearly labeled: +, –, and two AC (~) inputs
• Reliable silicon construction

Applications

• Small power supplies
• AC-to-DC conversion
• LED lighting circuits
• Battery chargers
• Home appliance control boards
• General-purpose rectification

DB107-datasheet
