2 Channel 5V Relay Module | Dual Relay Board 10A for Arduino, ESP32, Raspberry Pi & Automation

2 Channel 5V Relay Module | Dual Relay Board 10A for Arduino, ESP32, Raspberry Pi & Automation

The 2 Channel 5V Relay Module is a reliable relay switching board designed for controlling AC and DC electrical devices using a 5V control signal. The module contains two independent relays, allowing you to control multiple loads at the same time in automation and electronics projects.

Each relay can switch up to 250V AC or 30V DC at 10A, making it suitable for controlling lights, motors, pumps, fans, heaters, and other electrical appliances. The module can be driven directly from Arduino, ESP32, Raspberry Pi, PIC, AVR, ARM, and other microcontrollers using 3.3V or 5V logic signals.

Click here to view related products

Features

• 2 channel relay module
• Operating voltage: 5V DC
• Relay capacity: 250V AC / 30V DC @ 10A
• Works with 3.3V / 5V logic
• LED status indicators
• Transistor driver circuit
• Back EMF protection diode
• Screw terminal output
• Compact PCB design
• Compatible with Arduino / ESP / Raspberry Pi / PLC

Applications

• Arduino projects
• Home automation
• IoT projects
• Motor and pump control
• Lighting control
• Robotics
• Industrial automation
• DIY electronics
