2SK1317 MOSFET 1500V 2.5A N Channel Power TO-3P Package

2SK1317 MOSFET 1500V 2.5A N Channel Power TO-3P Package

The 2SK1317 is a high-voltage N-Channel Power MOSFET designed for medium-power, high-voltage switching applications. Rated at 1500V and 2.5A, this MOSFET provides fast switching, low on-resistance (RDS(on)), and high avalanche ruggedness, making it suitable for industrial, power supply, and high-voltage inverter circuits.

Housed in a TO-3P package, the 2SK1317 offers excellent thermal performance, durability, and reliable mounting for heavy-duty applications. It ensures efficient energy conversion while handling high voltage stresses, making it ideal for precision and industrial-grade power electronics.

Click here to view the related products

• Type: N-Channel Power MOSFET
• Drain-Source Voltage (Vds): 1500V
• Continuous Drain Current (Id): 2.5A
• Package Type: TO-3P
• Features:
• High-voltage capability for industrial applications
• Low RDS(on) for efficient switching
• Fast switching speed for high-frequency operation
• Excellent thermal and avalanche ruggedness
• Robust TO-3P packaging for durability and heat dissipation

Applications

• High-Voltage Switch Mode Power Supplies (SMPS)
• Inverter Circuits: Industrial and solar DC–AC conversion
• Motor Drives: Medium-power AC/DC motor control
• UPS Systems: Reliable high-voltage switching for backup power
• Industrial Automation: Control of machinery and high-voltage equipment
• High-Voltage Lighting Ballasts and Power Amplifiers

2sk1317-mosfet-datasheet

*Product image for illustration purposes only, actual product may vary.
