This is a 4 Channel 24V Relay Module. Using a high-power relay, the maximum control load DC 30V 10A / AC 250V 10A. In line with international safety standards, the control area and the load area with isolation slot. Each channel has a relay on the LED indication.
Features:
- Header Connector for connecting power and trigger voltage.
- LED on each channel indicates relay status.
- Power Battery Terminal (PBT) for easy relay output and aux power connection.
Specifications :-
| Trigger Voltage (VDC) | 24 |
| Trigger Current (mA) | 20 |
| Switching Voltage (VAC) | 250@10A |
| Switching Voltage (VDC) | 30@10A |
| Operating Temperature (C) | -40 to 85 |
| Opt. Relative Humidity(RH) | 20% 85% |
| Storage condition () | 65 to 125 |
| Length (mm) | 74 |
| Width (mm) | 44 |
| Height (mm) | 17 |
| Weight (gm) | 50 |
* product image for illustration purposes only. actual product may vary.
