74HC541 IC – (SMD Package) – Octal 3-State Buffer/Line Driver IC (74541 IC)

29.00 Excluding tax

Spread the components

The 74HC541 is an octal non-inverting buffer/line driver with 3-state outputs. The device features two output enables (OE1 and OE2). A HIGH on OEn causes the outputs to assume a high-impedance OFF-state. Inputs include clamp diodes that enable the use of current limiting resistors to interface inputs to voltages in excess of VCC.

Features:-

• Non-Inverting outputs

• Complies with JEDEC standard no. 7A

• Input level: CMOS level

• HBM JESD22-A114F exceeds 2000 V

• MM JESD22-A115-A exceeds 200 V

• Multiple package options

• Specified from -40 ° C to +85 ° C and from -40 ° C to +125 ° C

Specification:-

Symbol Parameter Value Unit
VCC Supply Voltage − 0.5 to + 7.0V V
IIK DC Input Diode Current ±20 mA
IOK DC Output Diode Current ±20 mA
IO Output Current ± 35 mA
ICC or IGND DC VCC or GND Current, per pin ± 75 mA
TSTG Storage Temperature Range − 65°C to + 150 °C
Ptot Power Dissipation 500  mW

74hc541-ic-datasheet

* product image for illustration purposes only. actual product may vary.
