A2212 – 1000KV BLDC Brushless Motor

358.00 Excluding tax

Spread the components

This is a A2212 brushless out runner motor specifically made to power Quadcopters and Multi rotors. It is a 1000kV motor. It provides high performance, super power and brilliant efficiency. These motors are perfect for medium size quadcopters with 8 inch to 10 inch propellers. With out 3S LiPo battery, our 30A ESC and our high efficiency 10″ propellers these motors provide up to 800gms. Using 4 of these motors on a quadcopter with our propellers will give you a total of 3.2 kg thrust! Use this to build powerful and efficient quadcopters.

Perfect with our F450 quadcopter frame. Our 30A ESCs can be used to drive the motor.

Specifications:-

  1. KV: 1000
  2. No load Current : 10 V : 0.5 A.
  3. Current Capacity: 12A/60s
  4. No Load Current @ 10V: 0.5A
  5. No. Of Cells: 2-3 Li-Poly
  6. Motor Dimensions: 27.5 x 30mm
  7. Shaft diameter : 3.175mm.
  8. Minimum ESC Specification: 18A (30A Suggested)
  9. Thrust @ 3S with 1045 propeller: 800gms approx.
  10. Thrust @ 3S with 0945 propeller: 475gms approx.
  11. Thrust @ 3S with 0845 propeller: 475gms approx.

Note: This motor is bi-directional which means it can rotate in CW or CCW direction by swapping the polarity of input supply.

* product image for illustration purposes only. actual product may vary.
