CD54 6.8uH (6R8) SMD Power Inductor

32.00 Excluding tax

Spread the components

A CD54 6.8uH Surface Mount Power Inductor (6.8 microH) is a 2-terminal passive device having a coil of wire wound wrapped around a core. A core may be magnetic metal or air to produce a high inductance in the wire. The terminals are pads for a surface mounting. When we apply a current through the inductor, a magnetic field is generated around it. The magnetic field generated by using a magnetic core will be much much stronger than others.

Applications: Useful in Mobile phone, PDA, MP3, DSC/DVC, portable DVD etc as DC-DC Converter inductors.

Features:-

  • Ferrite drum core construction.
  • Magnetically unshielded.
  • Moisture Sensitivity Level: 1
  • Halogen Free available.
  • Solder reflow temperature: 260 peak.

Specifications:-

Material Core Ferrite
Inductance(uH) 6.8
Tolerance(%) 20
Current Rating (A) 2.1
DC Resistance (DCR)(mΩ) at 20°C 0.08
Test Frequency (Hz) 100K/0.3V
Mount Surface Mount.
Operating Temperature (°C) -40 ~ 100

* product image for illustration purposes only. actual product may vary.
