IRF3205 MOSFET 55V 110A N Channel HEXFET Power TO-220 Package

IRF3205 MOSFET 55V 110A N Channel HEXFET Power TO-220 Package

The IRF3205 is a high-current N-Channel HEXFET Power MOSFET designed for low-voltage, high-current switching and power management applications. Rated at 55V and 110A, it features ultra-low on-resistance (RDS(on)), fast switching, and excellent thermal performance, making it ideal for switch-mode power supplies, motor controllers, automotive electronics, and industrial high-current systems.

Housed in a TO-220 package, the IRF3205 provides efficient heat dissipation, mechanical durability, and reliable mounting, ensuring stable operation under high-current and high-frequency conditions. Its HEXFET structure ensures maximum efficiency, minimal conduction losses, and robust performance.

Click here to view the related products

• Type: N-Channel HEXFET Power MOSFET
• Drain-Source Voltage (Vds): 55V
• Continuous Drain Current (Id): 110A
• Package Type: TO-220
• Features:
• High-current handling capability (110A)
• Extremely low RDS(on) for energy-efficient switching
• Fast switching for high-frequency power circuits
• Excellent thermal and avalanche ruggedness
• Robust TO-220 packaging for heat management and mounting

Applications

• Switch Mode Power Supplies (SMPS): High-efficiency DC–DC conversion
• Motor Drives: AC/DC motor control for industrial and automotive systems
• Automotive Electronics: High-current battery management and power distribution
• UPS Systems: Reliable high-current switching for backup power
• Industrial Automation: Heavy-duty power control in machinery and robotics
• Power Amplifiers and LED Drivers: Efficient high-current load switching

irf3205-mosfet-datasheet
