IRFBG30 N Channel Power Mosfet 1000V 3.1A TO-220 Package

IRFBG30 N Channel Power Mosfet 1000V 3.1A TO-220 Package

The IRFBG30 is a high-voltage N-channel Power MOSFET designed for efficient switching, robust performance, and reliable operation in medium-power, high-voltage applications.
With a drain-source voltage of 1000V and a continuous drain current of 3.1A, it offers low on-resistance, fast switching, and stable thermal performance, making it ideal for high-voltage power supplies, motor drives, inverters, and industrial electronics.
Housed in a TO-220 package, the IRFBG30 provides effective heat dissipation, easy mounting, and long-term reliability under demanding operating conditions.

Click here to view the related products

Features

• Ultra-High Voltage Rating: 1000V drain-source for demanding high-voltage circuits
• Moderate Current Handling: 3.1A continuous drain current for medium-power applications
• Low On-Resistance: Reduces conduction losses and improves efficiency
• Fast Switching Speed: Ideal for PWM, DC–DC converters, and motor control
• Rugged & Reliable: Stable operation under electrical and thermal stress
• TO-220 Package: Efficient heat dissipation and easy integration
• N-Channel MOSFET: Suitable for low-side switching in high-voltage circuits
• Wide Temperature Range: Reliable performance in industrial and consumer electronics

Applications

• High-voltage DC–DC converters – efficient power regulation
• Switch-mode power supplies (SMPS) – high-voltage switching
• Motor control circuits – medium-power DC motor drives
• Power inverters & UPS systems – dependable backup power operation
• Industrial automation & instrumentation – high-voltage load switching
• Battery-powered devices – load switching and protection
• Lighting systems – LED drivers and electronic dimmers
• Renewable energy systems – solar, wind, and hybrid power conversion
• General-purpose medium-power high-voltage switching
