Lithium Polymer Lipo Rechargeable Battery KP 104065 3.7V 5000mAH

The KP 104065 3.7V 5000mAH Lithium Polymer Battery is a high-capacity, robust, and energy-efficient rechargeable cell designed for devices that require long-lasting and reliable power. The model number “104065” indicates approximate physical dimensions—10 mm thickness, 40 mm width, and 65 mm length—providing a compact yet powerful energy solution.

With its large 5000mAH capacity, this Li-Po battery is well-suited for high-drain electronic products such as smart displays, advanced IoT systems, handheld communication equipment, medical devices, GPS units, and consumer electronics. It offers stable output voltage, low internal resistance, and high energy density, ensuring consistent performance for extended durations.

Click here to view the related products

Features

• High-capacity 5000mAH rating for long runtime
• Stable 3.7V nominal voltage output
• High energy density Lithium-Polymer chemistry
• Compact rectangular design suitable for mid-size devices
• Lightweight compared to other battery chemistries
• Supports CC/CV standard charging up to 4.2V
• Low self-discharge rate for excellent standby time
• Long cycle life with proper charge/discharge conditions
• Optional built-in protection circuit (overcharge, discharge, short circuit)

Specifications

• Model: KP 104065
• Nominal Voltage: 3.7V
• Capacity: 5000mAH
• Battery Type: Lithium Polymer (Li-Po)
• Full Charge Voltage: 4.2V
• Charging Method: CC/CV (Constant Current / Constant Voltage)
• Standard Charge Rate: 0.5C
• Max Charge Rate: 1C
• Max Discharge Current: Typically 1C–2C (varies by manufacturer)
• Cycle Life: ~300–500 cycles
• Dimensions (Approx.):
• Thickness: 10 mm
• Width: 40 mm
• Length: 65 mm
• Weight: 70–90 g (approx.)
• Operating Temperature:
• Charge: 0°C to +45°C
• Discharge: –20°C to +60°C

Applications

• Portable entertainment and multimedia devices
• IoT devices and smart home electronics
• Tablets, handheld displays, and compact monitors
• GPS tracking systems
• Portable medical instruments and health devices
• Bluetooth speakers and audio systems
• Industrial handheld terminals
• Robotics, embedded applications, and development projects
• Backup power systems and DIY electronics
