The LM1086CT-ADJ (LM1086 Adjustable) is a high-performance low dropout (LDO) linear voltage regulator capable of delivering up to 1.5A output current with an adjustable output voltage. The output voltage can be set from 1.25V up to 12V (or higher, depending on input voltage) using only two external resistors, making it highly flexible for a wide range of power supply designs.

Thanks to its low dropout voltage (typically about 1.3V at full load), the LM1086 is ideal for post-regulation of DC-DC converters, 5V to 3.3V or 5V to lower voltage conversion, and battery-powered systems. The IC includes current limiting and thermal shutdown protection, ensuring safe and reliable operation.

Click here to view related products

Applications

• Adjustable low-voltage power supplies
• Post-regulation for switching power supplies
• 5V to 3.3V or lower voltage conversion
• Microcontroller, FPGA, and DSP power rails
• Embedded systems and development boards
• Battery-powered equipment
• Industrial and consumer electronics

Features

• Output Type: Adjustable
• Output Voltage Range: 1.25V to ~12V (set by external resistors)
• Maximum Output Current: 1.5A
• Low Dropout Voltage: Typically ~1.3V at 1.5A
• Regulator Type: Positive LDO linear regulator
• Built-in thermal shutdown and current limiting protection
• Excellent line and load regulation
• Requires only two resistors to set output voltage
• Available in TO-220 (LM1086CT) and SMD packages

LM1086CT-ADJ Datasheet
