LM335 Temperature Sensor

LM335 Temperature Sensor

The LM335 is a precision analog temperature sensor that operates like a temperature-dependent Zener diode, with an output voltage linearly proportional to absolute temperature (in Kelvin). It provides 10 mV per Kelvin (10 mV/K), making it easy to measure temperature using simple analog or ADC circuits.

The LM335 is factory calibrated and can be easily adjusted with a single external resistor for higher accuracy. It is widely used in temperature measurement, compensation, and control circuits, as well as in weather stations, laboratory instruments, and industrial electronics.

Click here to view related products

Applications

• Microcontroller and ADC-based temperature measurement
• Temperature monitoring and control systems
• Weather stations and environmental monitoring
• Power supply temperature compensation
• Battery chargers and thermal protection circuits
• Industrial instrumentation and laboratory equipment

Features

• Type: Precision analog temperature sensor
• Output scale: 10 mV per Kelvin (10 mV/K)
• Operates like a temperature-dependent Zener reference
• High accuracy and good linearity
• Can be calibrated with one external resistor
• Low self-heating
• Low cost and easy to use
• Simple 3-pin interface
• Package options: TO-92 / TO-46 (depending on variant)
