MCP73831 Li ion Battery Charger IC SMD SOT 23 Package

MCP73831 Li ion Battery Charger IC SMD SOT 23 Package

The MCP73831 is a highly integrated, linear charge management controller IC designed for single-cell Lithium-Ion or Lithium-Polymer batteries.

It provides the complete charging algorithm — constant-current / constant-voltage (CC/CV) — using a minimal number of external components. The device automatically controls the entire charging process, including preconditioning, fast-charge, and charge termination phases.

It features:

• Built-in pass transistor (no external MOSFET required)
• Integrated current sensing (no sense resistor needed)
• Reverse-discharge protection (prevents battery drain when input power is removed)
• Thermal regulation (reduces charge current when the IC temperature rises)
• Status output pin (STAT) for LED or microcontroller monitoring

The MCP73831 is available in a compact 5-lead SOT-23 surface-mount package, making it ideal for space-constrained portable products.

Click here to view related products

Features

• Single-cell Li-Ion / Li-Polymer battery charger
• Programmable fast-charge current (up to 500 mA typical)
• Fixed charge voltage options: 4.20 V, 4.35 V, 4.40 V, or 4.50 V (depending on variant)
• Input voltage up to 6 V
• Automatic end-of-charge termination
• Reverse-discharge and thermal protection
• Few external components required (just one resistor + a few capacitors)
• Small SOT-23-5 package for compact designs

Applications:-

• Lithium-Ion/Lithium-Polymer Battery Chargers
• Personal Data Assistants
• Cellular Telephones
• Digital Cameras
• MP3 Players
• Bluetooth Headsets
• USB Chargers

Specification:-

MCP73831_Datasheet
