PC817 2 Channel Optocoupler Isolation Module | Dual Channel Signal Isolation Board 3.6-24V Input 30V Output

PC817 2 Channel Optocoupler Isolation Module | Dual Channel Signal Isolation Board 3.6-24V Input 30V Output

The PC817 2 Channel Optocoupler Isolation Module is designed to provide electrical isolation between low-voltage control circuits and high-voltage or noisy circuits. The board uses two PC817 optocouplers, allowing safe signal transfer while protecting sensitive devices from voltage spikes, interference, and ground loop problems.

Each channel works independently, so different voltages can be controlled at the same time. The module can be connected directly to Arduino, Raspberry Pi, ESP32, PLC, microcontrollers, and industrial control boards for reliable I/O isolation.

Click here to view related products

Features

• PC817 2 channel optocoupler module
• Dual independent isolation channels
• Input voltage: 3.6V – 24V DC
• Output voltage: up to 30V DC
• High noise immunity
• Pull-up / pull-down selectable output
• Compact PCB design
• Easy pin connection
• Stable and reliable operation

Applications

• Microcontroller I/O isolation
• Arduino and Raspberry Pi projects
• PLC signal isolation
• Industrial automation
• Relay and MOSFET driving
• Noise suppression circuits
• Voltage level conversion
• DIY electronics projects
