PIC18F26K22 Microcontroller

PIC18F26K22 Microcontroller

The PIC18F26K22 is an 8-bit high-performance microcontroller from Microchip Technology, belonging to the PIC18 K22 family. It is designed for high speed, low power consumption, and enhanced peripheral integration.

The microcontroller uses RISC architecture and can operate at speeds up to 64 MHz (16 MIPS). It includes Flash program memory, making it easy to erase and reprogram, and is suitable for both low-power and high-performance embedded applications.

Click here to view related products

Features

• 8-bit PIC18 CPU (RISC architecture)
• Operating voltage: 1.8 V – 5.5 V
• Maximum clock frequency: 64 MHz (16 MIPS)
• Program memory: 64 KB Flash
• RAM: 3.8 KB
• EEPROM: 1 KB
• I/O pins: Up to 25 programmable digital I/O pins
• Timers:
• Timer0 (8/16-bit)
• Timer1, Timer3, Timer5 (16-bit)
• Timer2, Timer4, Timer6 (8-bit)
• Analog features:
• 10-bit ADC with up to 17 channels
• Comparators and voltage reference
• Communication interfaces:
• Enhanced USART (EUSART)
• SPI
• I²C (MSSP module)
• PWM / ECCP modules for motor and power control
• Interrupt system with priority levels
• Watchdog Timer (WDT) with low-power operation
• In-Circuit Serial Programming (ICSP)
• Low-power modes: Sleep, Idle, and Doze modes
• Applications
• Industrial automation and control systems
• Motor control and robotics
• Battery-powered and low-power embedded systems
• Data acquisition and monitoring systems
• Communication and interface devices
• Consumer electronics
• Medical and instrumentation equipment
• Educational and student embedded projects
