ATtiny85 IC 8 Bit AVR Microcontroller IC SMD Package

ATtiny85 IC 8 Bit AVR Microcontroller IC SMD Package

The ATtiny85 is an 8-bit AVR microcontroller manufactured by Atmel (now Microchip Technology). It belongs to the ATtiny family, which is designed for small, low-power, and low-cost embedded applications.

The ATtiny85 uses a Harvard architecture and a RISC instruction set, allowing most instructions to execute in a single clock cycle. It integrates Flash program memory, SRAM, EEPROM, GPIO pins, timers, ADC, and communication interfaces on a single chip.

The SMD package (such as SOIC-8 or VQFN) makes it ideal for compact PCB designs and surface-mount technology, commonly used in modern electronics.

Click here to view related products

Features

• 8-bit AVR RISC CPU
• Operating voltage:
• 1.8 V – 5.5 V (device dependent)
• Maximum clock frequency:
• Up to 20 MHz (with external clock)
• Program memory:
• 8 KB Flash
• Data memory:
• 512 bytes SRAM
• 512 bytes EEPROM
• I/O pins:
• 6 programmable digital I/O pins
• Timers/Counters:
• Two 8-bit timers
• One high-speed timer with PWM
• Analog features:
• 10-bit ADC with up to 4 input channels
• Communication interfaces:
• SPI
• I²C (via USI – Universal Serial Interface)
• PWM support
• Interrupt system
• Watchdog Timer (WDT)
• Low-power modes: Idle, ADC Noise Reduction, Power-down
• In-System Programming (ISP)
• Package types: SMD (SOIC-8, VQFN), also available in DIP-8

Applications

• Compact embedded systems
• Wearable and IoT devices
• LED controllers and light effects
• Sensor interfacing
• USB-based small projects
• Battery-powered electronics
• Robotics and automation modules
• Educational and DIY projects (Arduino-compatible)
