DK124 Power Management IC 24W DIP 8 Package

DK124 Power Management IC 24W DIP 8 Package

The DK124 is a highly integrated Power Management IC (PMIC) designed for off-line switch mode power supply (SMPS) applications up to 24 watts. It combines a high-voltage power MOSFET, a PWM controller, and essential protection features into a single DIP-8 package, minimizing external components and simplifying power supply design.

Engineered for high efficiency and low standby power, the DK124 supports universal AC input (85V–265V) and is suitable for isolated and non-isolated topologies such as flyback and buck converters. It ensures stable output regulation, high reliability, and comprehensive protection, making it ideal for consumer electronics and industrial control systems.

Click here to view related products

Features

• Integrated PWM controller and high-voltage MOSFET (650V)
• Wide input voltage range: 85V – 265V AC
• Output power capability: up to 24W (at 230V AC)
• Fixed 65kHz switching frequency for stable performance
• Built-in start-up circuit (no external resistor required)
• Cycle-by-cycle current limiting for overload protection
• Overvoltage, overcurrent, and over-temperature protection
• Under-voltage lockout (UVLO) for safe startup
• Auto-restart protection after fault removal
• Low standby power consumption (<0.3W typical)
• Soft-start function to minimize stress at power-up
• Compact DIP-8 package for easy PCB mounting

Applications

• AC–DC switching adapters and chargers
• LED lighting drivers and lamp power supplies
• Standby power and auxiliary power modules
• Set-top boxes, smart home devices, and consumer appliances
• Industrial control systems and embedded SMPS designs

DK124 Datasheet

*Product image for illustration purposes only, actual product may vary.
