IRL520 N Channel Mosfet 100V 10A

IRL520 N Channel Mosfet 100V 10A

The IRL520 is a logic-level N-channel Power MOSFET designed for efficient switching, medium-current handling, and reliable operation.
With a drain-source voltage of 100V and a continuous drain current of 10A, it provides low on-resistance, fast switching, and robust performance, making it ideal for microcontroller-driven circuits, DC–DC converters, motor drivers, and general-purpose load switching.
Its TO-220 package ensures efficient heat dissipation, easy mounting, and durable operation in both industrial and consumer applications.

Click here to view the related products

Features

• Logic-Level N-Channel MOSFET – compatible with 5V or 3.3V logic
• Voltage Rating: 100V drain-source
• High Current Handling: 10A continuous drain current
• Low On-Resistance: Reduces conduction losses and heat generation
• Fast Switching Speed: Ideal for PWM, motor control, and DC–DC converters
• TO-220 Package: Efficient heat dissipation and easy mounting
• Rugged & Reliable Design: Stable under thermal and electrical stress
• Wide Operating Temperature Range: Reliable in industrial and consumer electronics

Applications

• Microcontroller-based switching circuits – logic-level load control
• DC–DC converters – efficient medium-current regulation
• Motor control circuits – precise switching for DC motors
• Power amplifiers & audio systems – medium-current output stages
• LED drivers & lighting systems – low-to-medium voltage applications
• Switch-mode power supplies (SMPS) – efficient medium-current switching
• Battery-powered devices – reliable load switching
• General-purpose medium-current switching

IRL520 Mosfet Datasheet
