MCU Micro USB Breadboard 5V Power Supply Module

MCU Micro USB Breadboard 5V Power Supply Module

The Micro USB Breadboard Power Supply Module is a compact voltage regulator board designed to provide a stable 5V or 3.3V output directly to a standard MB102 breadboard.
It is powered through a Micro USB connector or an external DC input header.
The module includes an onboard voltage regulator and jumpers to switch between 5V and 3.3V output rails, making it ideal for powering microcontroller-based prototypes such as Arduino, ESP8266, ESP32, STM32, and sensor circuits.

Click here to view the related products

Note: This board comes with unsoldered header pin.

Pinouts:

• VCC: 5V Power Supply
• D- : USB D- Signal
• D+: USB D+ Signal
• ID: USB Identifier Signal for OTG Devices
• GND: Power Ground

Features

• Powered via Micro USB or external 6.5–12V DC input
• Provides stable 5V and 3.3V regulated output
• Dual power rails for breadboard compatibility
• Includes ON/OFF switch for convenience
• Up to 700–800 mA output current (depending on regulator type)
• Onboard LED power indicator
• Selectable voltage via jumpers (5V/3.3V)
• Compatible with MB102 standard breadboards
• Compact layout suitable for prototyping and development

Applications

• Power supply for Arduino, Raspberry Pi Pico, ESP8266/ESP32, and other MCUs
• Breadboard-based electronics prototyping
• Sensor and module testing on breadboard
• DIY IoT and embedded system development
• Educational electronics experiments
• Powering logic circuits, LEDs, and small drivers
• Portable project power regulation
