NE555 Timer IC Dip 8 Package

NE555 Timer IC Dip 8 Package

The NE555 is one of the most popular and widely used timer ICs in electronics, known for its simplicity, reliability, and versatility. In the DIP-8 (Dual In-Line Package), it is ideal for prototyping, breadboard use, educational projects, and through-hole PCB designs.

The NE555 can operate in monostable, astable, and bistable modes, making it suitable for generating accurate time delays, square waves, pulse-width modulation (PWM), and clock signals. It works over a wide supply voltage range and can source or sink relatively high output current, allowing it to directly drive LEDs, buzzers, relays (via transistor), and small loads.

Click here to view related products

Applications

• Time delay generators
• Oscillators and clock generators
• Pulse generators and PWM circuits
• LED flashers and blinkers
• Tone generators and alarm circuits
• Motor speed and light dimmer controllers
• Educational, hobby, and general-purpose electronics projects

Features

• Type: General-purpose timer IC
• Operating modes: Monostable, Astable, Bistable
• Wide supply voltage range: 4.5V to 16V (typical)
• High output drive capability (can source or sink up to ~200mA, depending on manufacturer)
• Good temperature stability
• Simple external component requirement
• Extremely popular, proven, and reliable design
• Package: DIP-8 (Through-hole)
• Easy to use on breadboards and prototype boards

NE555 Datasheet
