NEO 6M GPS Module

NEO 6M GPS Module

The NEO-6M GPS Module is a high-performance GPS receiver based on the u-blox NEO-6M chipset.
It provides accurate location, altitude, speed, and time data and is widely used in navigation, tracking, mapping, and IoT projects.
The module includes an onboard ceramic antenna, optional u.FL connector for external antennas, and a backup battery to store configuration and satellite data for faster cold starts.

It communicates with microcontrollers using UART serial communication, making it compatible with Arduino, ESP32, Raspberry Pi, STM32, and many other boards.

Click here to view the related products

Features :-

• 5Hz position update rate
• Operating temperature range: -40 TO 85°C UART  TTL socket
• EEPROM to save configuration settings
• Rechargeable battery for Backup
• The cold start time of 38 s and Hot start time of 1 s
• Supply voltage: 3.3 V
• Configurable from 4800 Baud to 115200 Baud rates. (default 9600)
• SuperSense ® Indoor GPS: -162 dBm tracking sensitivity
• Support SBAS (WAAS, EGNOS, MSAS, GAGAN)
• Separated 18X18mm GPS antenna

Applications

• GPS navigation systems
• Vehicle tracking and fleet management
• Drone and RC aircraft positioning
• Robotics navigation and mapping
• Personal trackers (kids, pets, assets)
• Outdoor location logging (hiking, cycling)
• Marine navigation
• Time synchronization systems
• GIS and surveying projects
• IoT location-based applications
• Weather balloons or high-altitude projects
• Geo-tagging and mapping systems
