PIC16F818 Microcontroller

PIC16F818 Microcontroller

The PIC16F818 is an 8-bit Flash microcontroller developed by Microchip Technology, part of the PIC16F family. It is designed for low-power, cost-effective embedded applications, particularly those needing analog functionality alongside digital control.

It uses Harvard architecture with a RISC instruction set, allowing most instructions to execute in a single clock cycle. The device operates at up to 20 MHz, has Flash program memory for easy reprogramming, and integrates analog peripherals like ADC and comparators, making it suitable for sensor-based applications.

Click here to view related products

Features

• 8-bit PIC CPU (RISC architecture)
• Operating voltage: 2.0 V – 5.5 V
• Maximum clock frequency: 20 MHz
• Program memory: 2 KB Flash
• RAM: 128 bytes
• EEPROM: 128 bytes
• I/O pins: Up to 15 programmable digital I/O pins
• Timers:
• Timer0 (8-bit)
• Timer1 (16-bit)
• Analog features:
• 10-bit ADC with up to 6 input channels
• 2 analog comparators
• Communication interfaces:
• USART
• I²C (MSSP module)
• PWM / CCP module
• Interrupt system
• Watchdog Timer (WDT)
• In-Circuit Serial Programming (ICSP)
• Low-power sleep mode

Applications

• Embedded control systems
• Sensor-based applications
• Home and industrial automation
• Small robotics projects
• Consumer electronics
• Educational and student projects
• Low-power battery-operated devices
