SG3524 Regulating Pulse Width Modulator IC DIP-16 Package

22.00 Excluding tax

Spread the components

SG3524 incorporate all the functions required in the construction of a regulating power supply, inverter, or switching regulator on a single chip. It can be used as the control element for high-power-output applications. SG3524 was designed for switching regulators of either polarity, transformer-coupled dc-to-dc converters, transformerless voltage doubles, and polarity-converter applications employing fixed-frequency, pulse-width modulation (PWM) techniques. The complementary output allows either single-ended or push-pull application. Each device includes an on-chip regulator, error amplifier, programmable oscillator, pulse-steering flip-flop, two uncommitted pass transistors, a high-gain comparator, and current-limiting and shutdown circuitry.

Features:-

  • Complete Pulse-Width Modulation (PWM) Power-Control Circuitry
  • Uncommitted Outputs for Single-Ended or Push-Pull Applications
  • 8 mA (TYP) Standby Current

Specification:-

Parameter Value
Part number SG3524
Topology Boost, Buck, Flyback, Forward, Full-Bridge, Half-Bridge, Push-Pull
Control method Voltage
VCC(Min) (V) 8
VCC(Max) (V) 40
Frequency(Max)(kHz) 722
UVLO thresholds on/off(V)
Duty cycle(Max)(%) 45
Gate drive (Typ) (A) 0.05
Features Adjustable Switching Frequency, Error Amplifier, Multi-topology
Rating Refer Data Sheet
Operating temperature range (°C) 0 to 70
Package Group PDIP|16
Package size: mm2:W x L (PKG) 16PDIP: 181 mm2: 9.4 x 19.3 (PDIP|16)

sg3524-ic-datasheet

* product image for illustration purposes only. actual product may vary.
