SW-18020P Sealed Vibration Switch/Shaking Vibration Sensor Switch

SW-18020P – Sealed Vibration Switch, Shaking Vibration Sensor SwitchVibration sensor SW-18020 is a piezoelectric accelerometer that senses vibration. It is a switch that reacts (connects) to vibration, ie. moves. When a force acts on the sensor, it is connected, and when the force does not work, it is not connected. This product is known as 2801 ball sensor, SW-520D, SW-520D Vibration Sensor, SW18020P, SW-18020P, SW-18020 Vibration Sensor, Tilt Sensor, and SW-18020 Vibration Sensor.

Specifications:

• Part Number: SW-18020P
• Max Voltage: 12V
• Max Current: 50mA
• Conductive Time: ~2ms
• Closed Resistance: < 10 ohm
• Open Resistance: > 10M ohm
• Operating Temperature Range: -40°C ~ 80°C
• Pull Force of Terminal: 500gf for 1 min
• Operating Lifespan: up to 200,000 cycles
• Length: 11 mm
• Diameter: 4.4 m
• Length including Pin: 21.5mm
• Approx Weight: 2 gm

Application:

• Security devices
• Toys
• Electronic scales

SW-18020P Datasheet
