TNY267PN Power Integrations Off Line Switcher IC

TNY267PN Power Integrations Off Line Switcher IC

The TNY267PN is a highly integrated low-power AC-DC off-line switcher IC from Power Integrations’ TinySwitch family, designed to build compact, efficient, and low-cost switch-mode power supplies (SMPS). It integrates a high-voltage power MOSFET, PWM controller, oscillator, soft-start, and comprehensive protection features into a single device, significantly reducing external component count and simplifying power supply design.

The TNY267PN is ideal for low-power AC-DC converters and standby power supplies, offering high efficiency, ultra-low standby power consumption, and excellent reliability. It is widely used in chargers, adapters, standby power modules, consumer electronics, and auxiliary power supplies.

Click here to view related products

Applications

• Mobile and small device chargers
• AC-DC adapters
• Low-power SMPS
• Standby and auxiliary power supplies
• Consumer electronics and home appliances
• IoT and smart device power modules
• Low-power LED drivers

Features

• Type: Low-power AC-DC off-line switcher IC with integrated MOSFET
• Manufacturer: Power Integrations
• Family: TinySwitch
• Integrated high-voltage power MOSFET
• Wide AC input range: 85–265V AC (with proper design)
• High efficiency and ultra-low no-load / standby power consumption
• Built-in soft-start, current limiting, thermal shutdown, and over-voltage protection
• Auto-restart fault protection
• Frequency jittering for reduced EMI
• Requires very few external components
• Package: PN (DIP-8 / PDIP-8)
• High reliability and long service life

TNY267PN-IC Datasheet
