The G15N60 is a fast IGBT in NPT-technology. The G15N60 IS 75% lower Eoff compared to previous generation combined with low conduction losses. The G15N60 has VCE of 600V, IC of 15A, VEC(sat) of 2.3V, and Tj of 150 degree. It is designed for :
1.Motor controls
2. Inverter.
Features:-
• Short circuit withstand time – 10 µs
• NPT-Technology for 600V applications offers:
– very tight parameter distribution
– high ruggedness, temperature stable behavior
– parallel switching capability
• Qualified according to JEDEC1 for target applications
• Pb-free lead plating; RoHS compliant
Specification:-
| Symbol | Description | Ratings | Units |
| VCE | Collector-emitter voltage | 600 | V |
| IC | DC collector current | 15 | A |
| Tj | Operating junction | 150 | °C |
| Ts | Soldering temperature | 260 | °C |
| Tstg | Storage temperature | -55 | °C |
| Ptot | Power dissipation | 139 | W |
| tsc | Short circuit withstand time | 10 | µs |
| VG E | Gate-emitter voltage | ±20 | V |
* product image for illustration purposes only. actual product may vary.
