HM 10 Bluetooth Module

HM 10 Bluetooth Module

The HM-10 module provides a simple UART interface, allowing seamless wireless communication between devices.
It is fully compatible with Arduino, Raspberry Pi, ESP32, and other 3.3V/5V logic systems through its TTL serial interface.
Using AT commands, users can easily configure parameters such as the module name, baud rate, transmission power, and operation mode (Master/Slave).

This module can communicate directly with BLE-enabled smartphones or tablets without needing a custom driver, which makes it perfect for Bluetooth app-controlled projects.

Click here to view the related products

Features :-

• BT Version: Bluetooth Specification V4.0 BLE
• Send and receive no bytes limit.
• Working frequency: 2.4GHz ISM band
• Modulation method: GFSK(Gaussian Frequency Shift Keying)
• RF Power: -23dbm, -6dbm, 0dbm, 6dbm, can modify through AT Command AT+POWE.
• Speed: Asynchronous: 6K Bytes
• Synchronous: 6K Bytes
• Security: Authentication and encryption
• Service: Central & Peripheral UUID FFE0,FFE1
• Power: +3.3VDC 50mA
• Long range: Open space have 100 Meters with iphone4s
• Power: In sleep mode 400uA~1 .5mA, Active mode 8.5mA.
• Working temperature:–5 ~ +65 Centigrade
• Size: HM-10 26.9mm x 1 3mm x 2.2 mm.

Applications

• Internet of Things (IoT) devices
• Home automation systems
• Smart health and fitness gadgets
• Wireless sensors and data loggers
• Bluetooth-controlled robots
• Communication between microcontrollers and mobile apps

Advantages

• Energy-efficient BLE communication
• Long-range and stable connection
• Supports both Android and iOS devices
• Compact and easy to integrate
• Ideal for modern wireless applications
