L6205 DMOS Dual Full Bridge Driver IC SMD Package

L6205 DMOS Dual Full Bridge Driver IC SMD Package

The L6205 is a DMOS dual full-bridge driver IC designed for controlling DC motors, stepper motors, and other inductive loads. It integrates two independent full H-bridges using low-RDS(on) DMOS power transistors, allowing efficient bidirectional control of motors with high current capability.

The device operates over a wide supply voltage range and provides built-in protection features such as overcurrent protection, thermal shutdown, and undervoltage lockout, ensuring reliable operation in demanding applications. Available in a surface-mount (SMD) package, the L6205 is suitable for compact and high-performance motor control designs.

Click here to view related products

Features

• Dual full H-bridge DMOS motor driver
• Low RDS(on) DMOS outputs for high efficiency
• Drives DC motors, bipolar stepper motors, and inductive loads
• Wide operating supply voltage range
• High output current capability
• Built-in overcurrent protection
• Thermal shutdown protection
• Undervoltage lockout (UVLO)
• Logic-level compatible inputs
• Surface-mount SMD package for compact PCB layouts

Applications

• DC motor control systems
• Bipolar stepper motor drivers
• Robotics and automation equipment
• CNC machines and positioning systems
• Industrial motor control applications
• Printers, scanners, and office equipment
• Mechatronics and motion control systems
