NE555 Frequency Adjustable Pulse Generator Module

NE555 Frequency Adjustable Pulse Generator Module

The NE555 Frequency Adjustable Pulse Generator Module is a small, easy-to-use board based on the popular NE555 timer IC.
It is designed to generate adjustable square-wave pulses with controllable frequency and duty cycle.
Using onboard potentiometers, you can fine-tune the signal output, making it useful for testing circuits, driving motors, LEDs, servos, and more.

The module outputs a clean square wave signal and can be used as a standalone function generator for many electronics experiments. It operates on a 5V–15V supply, making it compatible with a wide range of projects.

Click here to view the related products

Features

• Based on the NE555 timer IC
• Generates adjustable square wave pulses
• Adjustable frequency via onboard potentiometer
• Adjustable duty cycle (depending on module design)
• Wide operating voltage: typically 5V – 15V
• Output waveform: Square wave
• Maximum output current up to 200mA (from NE555 IC)
• Onboard status LED indicating output pulse
• Stable and reliable oscillation
• Easy-to-use 3-pin interface: VCC, GND, Output

Applications

• Test signal generation
• PWM generation for motor speed control
• LED brightness control
• Clock pulse generation for digital circuits
• Tone generation for buzzers
• Servo motor control (basic PWM)
• Timing experiments and electronic learning
• Triggering circuits and oscillators
• Sensor simulation
• DIY function generator
• Frequency-related experiments in labs
• Sequential logic circuit driving
