Q250 4 Axis Quadcopter Frame Kit

888.00 Excluding tax

Spread the components

The Q250 is a mini-size quadcopter frame. The Q250 Quadcopter Frame is known for its simple and compact design. The special thing about this frames design is it features red and white fiberglass arms which have the downward angle design.

This Q250 Quadcopter Frame is made from Glass Fiber which makes it tough and durable. They have the arms of ultra-durable Polyamide Nylon which are the stronger molded arms having a very good thickness so no more arm breakage at the motor mounts on a hard landing. The arms have support ridges on them, which improves stability and provides faster forward flight.

The frame is lightweight and possesses thick arms, so as to give them good mechanical strength. The mini-size design of this quadcopter frame makes it aerodynamically efficient which will require lower throttle to hover. The design allows the whole take-off weight to be controlled at about 500 grams.

They are strong, light, and have a sensible configuration including a PCB(Printed Circuit Board) with which you can directly solder your ESCs to the Quadcopter. So, making the Quadcopter build fast and easy. So, it avoids the use of extra PDB(Power Distribution Board) and makes the mounting clean and neat.

The frame has the wheel base of 250mm and weighs around 120gm. It features a mounting tab at the front end on the bottom plate of the main frame for mounting cameras and other accessories.

It comes with pre-threaded brass sleeves for all of the frame bolts, so attaching the arms to the main frame is done within few minutes. Also, it requires one size of bolt for the overall build and thus a unique one size hex wrench which makes hardware mounting very convenient. This feature ofQ250 Quadcopter Frame is responsible for fast assembling and disassembling.

Features :-

  • Made by advanced engineering material, super strong & smooth
  • The frame is tough and durable.
  • The arms have a downward angle design.
  • The main glass fiber frame has good strength.
  • The arm equips support ridges for the safe landing.
  • Features pre-threaded brass sleeves.
  • In-built power distribution board.

Specifications :-

Model Q250
Material Glass Fiber + Polyamide Nylon
Wheelbase (mm) 250
Weight (gm) 118
Motor Mounting Hole Dia. 3mm

* product image for illustration purposes only. actual product may vary.
