Toshiba TLP2366 Optocoupler Digital Output 1 Channel SOP 5

Toshiba TLP2366 Optocoupler Digital Output 1 Channel SOP 5

The TLP2366 is a high-speed digital optocoupler from Toshiba designed to provide galvanic isolation and fast logic signal transfer between circuits operating at different voltage levels or environments.

It features an infrared LED input and an integrated high-gain, high-speed CMOS output buffer, enabling high-speed digital data transmission with excellent noise immunity.

The TLP2366 supports data rates up to 10 Mbps, making it ideal for isolating high-speed logic signals in industrial, communication, and automation systems. Its low input current, high common-mode noise immunity (CMR), and low power consumption make it suitable for modern low-power digital electronics.

Housed in a compact SOP-5 package, the device provides a high isolation voltage (typically 3750 Vrms) while maintaining stable long-term performance.

Click here to view the related products

Features

• High-speed digital optocoupler
• Data rate up to 10 Mbps
• CMOS logic-compatible output
• High common-mode rejection (CMR)
• Low input drive current
• Low propagation delay and jitter
• Compact SOP-5 SMD package
• High isolation voltage (~3750 Vrms)
• Low power consumption
• High noise immunity for industrial environments
• Wide operating temperature range

Applications

• High-speed logic signal isolation
• Industrial control systems
• PLCs and automation equipment
• Microcontroller/FPGA/SoC isolation
• Digital communication interfaces
• RS-232 / RS-485 / CAN bus isolation
• Switching power supply feedback
• Motor control and inverter systems
• Data acquisition and measurement systems
• IGBT/MOSFET gate signal isolation (low-speed logic)

TLP2366 Datasheet
