MC3403 Quad Low-Power Operational Amplifier IC DIP-14 Package

56.00 Excluding tax

Category: Tag:
Spread the components

The  MC3403 are quadruple operational amplifiers similar in performance to the µA741, but with several distinct advantages. They are designed to operate from a single supply over a range of voltages from 3 V to 36 V. Operation from split supplies also is possible, provided the difference between the two supplies is 3 V to 36 V. The common-mode input range includes the negative supply. Output range is from the negative supply to VCC – 1.5 V. Quiescent supply currents are less than one-half those of the µA741. The MC3403 is characterized for operation from 0°C.

Features:-

• Wide Range of Supply Voltages, Single Supply . . . 3 V to 36 V or Dual Supplies

• Class AB Output Stage

• True Differential Input Stage

• Low Input Bias Current

• Internal Frequency Compensation

• Short-Circuit Protection

• Designed to Be Interchangeable With Motorola MC3303

Specification:-

Parameter Min Type Max Unit
Input offset voltage 2 10 m V
Temperature coefficient of input offset voltage 10 µV/°C
Input offset current 30 50 n A
1 Unity-gain bandwid 1 1 M
Total supply current 2.8 7 m A

mc3403-ic-datasheet

* product image for illustration purposes only. actual product may vary.
