MCT62 IC – Dual Channel Phototransistor Optocoupler IC

118.00 Excluding tax

Spread the components

The MCT62 Optocouplers have two channels for density applications. For four channel applications, two-packages fit into a standard 16-pin DIP socket. Each channel is an NPN silicon planar photo transistor optically coupled to a gallium arsenide infrared emitting diode.

Features:-

• Two isolated channels per package

• Two packages fit into a 16 lead DIP socket

• Choice of three current transfer ratios

• Underwriters Laboratory (U.L.) recognized File E90700

Applications:-

• AC Line/Digital Logic – Isolate high voltage transients

• Digital Logic/Digital Logic – Eliminate spurious grounds

• Digital Logic/AC Triac Control – Isolate high voltage transients

• Twisted pair line receiver – Eliminate ground loop feedthrough

• Telephone/Telegraph line receiver – Isolate high voltage transients

• High Frequency Power Supply Feedback Control – Maintain floating grounds and transients

• Relay contact monitor – Isolate floating grounds and transients

• Power supply monitor – Isolate transients

Specification:-

Symbol Parameter Value Unit
IF Forward current 60 mA
PD Power dissipation 100 mW
VR Reverse Voltage 3 V
Tstg Storage temperature range – 55 to + 150 °C
TOPR Operating Temperature – 55 to + 150 °C
TSOL Lead Solder Temperature 260 for 10 sec °C
IF(pk) Forward Current – Peak (PW = 1µs, 300pps) 3 A
IC Collector current 30 mA

* product image for illustration purposes only. actual product may vary.
