PAM8403 Audio Amplifier SOP-16 Package

The PAM8403 is a 3W, class-D audio amplifier. It offers low THD+N allowing it to achieve high-quality sound reproduction. The new filterless architecture allows the device to drive the speaker directly requiring no low-pass output filters, thus saving system cost and PCB area. With the same numbers of external components, the efficiency of the PAM8403 is much better than that of Class-AB cousins. It can extend the battery life, which makes it well suited for portable applications.

Applications:

• LCD Monitors / TV Projectors
• Notebook Computers
• Portable Speakers
• Portable DVD Players, Game Machines
• Cellular Phones/Speaker Phones

Specifications:

• Part No: PAM8403DR
• Manufacturer: Diodes Incorporated
• Type: Class D
• Output Type: 2-Channel (Stereo)
• Max Output Power x Channels @ Load: 3W x 1 @ 4Ohm
• Voltage – Supply: 2.8V ~ 5.5V
• Features: Depop, Short-Circuit, and Thermal Protection
• Mounting Type: Surface Mount
• Operating Temperature: -40°C ~ 85°C (TA)
• Package / Case: 16-SOIC (0.154?, 3.90mm Width)

*product image for illustration purposes only. actual product may vary.
