Ai Thinker NF-01-N Wireless Transceiver is a 100mW power 2.4G wireless module with high airspeed (up to 2Mbps), SPI interface, a pure hardware module for transceiver and it has high stability, high cost performance, good spectrum test characteristics, small Volume, using all industrial grade components.
NF-01-N can be widely used in various Internet of Things applications, suitable for wireless mouse and keyboard, wireless remote control, somatosensory equipment, active RFID, NFC, low-power self-organizing network wireless sensor network nodes, etc.
- DIP-8 ultra-small package
- built-in 2.4G antenna, compact size, easy to use
- Supports six channels of data reception
- Supports general modulation methods such as GFSK/FSK
- Supports 2Mbps/1Mbps/250Kbps data rate
- Multi-frequency point: 126 frequency points to meet the needs of multi-point communication and frequency hopping communication
- Internally integrated high PSRR LDO
- Wide supply voltage range: 1.9~3.6V
- Average emission current as low as 110mA
- Receive sensitivity: -96dBm@250kbps
- Maximum transmit power: 7dBm
- 4-wire SPI interface with speeds up to 10MHz
- Internally integrated intelligent ARQ baseband protocol engine
- Transceiver data hardware interrupt output
- Support 1bit RSSI output
|Power Supply||1.9~3.6V, Typical 3.3V|
|Average emission current||as low as 110mA|
|Maximum transmit power||7dBm|
* product image for illustration purposes only. actual product may vary.
