VS1003 VS1003B MP3 Module Decoding Containing Microphones STM32

795.32 Incl. Tax

Share with Friends

This is VS1003 VS1003B MP3 Module Decoding Containing Microphones STM32 Module with complete MP3/WMA/MIDI audio decoder and ADPCM encoder which features a high-quality stereo DAC (Digital to Analog Converter), a 16-bit adjustable ADC (Analog to Digital Converter) and a high-quality stereo earphone driver (30 Ohm).

This module is ideal for adding audio decoding and encoding capabilities to embedded systems.

Features :-

  • Separate analog, digital, and IO power supply
  • Serial data and control interface (SPI)
  • 1 headphone and audio output interface
  • 1 microphone for recording, support audio encoding format
  • 1 line input interface; supports MP3 and WAV stream
  • Power indicator light
  • Onboard 3.3 V and 2.5 V LDO chip AMS-1117,
  • 12.288 MHz crystal


Input Supply Voltage (VDC) 5
Maximum Operating Current (A) 0.8
Length (mm) 44
Width (mm) 40
Height (mm) 11

* product image for illustration purposes only. actual product may vary.
